High Quality OEM/ODM China Factory CE ISO Standard Full Automatic Iron Steel Metal Quick Cutting Horizontal Band Sawing Machine

FOB Reference Price:Get Latest Price
US $1,800-2,500 / Sets | 1 Set/Sets (Min. Order)
Model Number:
S-2840
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
JULIHUANG
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Warranty:
1 Year
Certification:
Full-Automatic, CE ISO
Cutting Capacity:
Circular280mm Square400x230mm
Saw blade speed:
25/32/40/58/70 m/min
Saw blade size:
27x0.9x3505 mm
Hydraulic motor:
0.55 kw
Worktable height:
630 mm
Use:
Metal
Key Words:
Band Sawing Machine
Name:
Band Sawing
Condition:
New
Voltage:
220V/380V/415V/460V/Custom
Rated Power:
2.2kw
Dimension(L*W*H):
1900x1150x1300
Weight:
780kg
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Plastic film for wrapping,Wooden box packing
Port
Ningbo/Shanghai



Band sawing machine large and  high quality and precision CE,ISO,UKAS,CCC leading company,famous brand

Technical data:
1) Max. process dimensions: Φ280mm, 400 x 280mm
2) Process speed: 23, 49, 77m/min (3-step)
3) Adjustable pattern blade feeding speed: belt speeding
4) Band saw dimensions: 3,850 x 27 x 0.9mm
5) Feeding pattern: hydraulic pressure
6) Max. length of one-way feeding: 500mm
7) One set feeding times: 9,999
8) Controlled precision: 0.02mm
9) Synthesized cutting precision: ±0.20mm
10) Main motor: 2.2kW
11) Oil-pump motor: 1.1kW
12) Machine weight: 1,250kg

Outer packing:
Packing dimensions: 2,000 x 1,200 x 1600mm

We can provide you with various specifications.





Q:Are you a factory or trading company?

A:We are the manufacturer and we have more than 30 years factory experience. And we welcome you to visit us.



Q:How to place order?

A:Please have a complete discussion with sale representative before order.



Q:What are the payment options?

A:L/C at sight and T/T. Please advise us if you may need other payment terms before order.



Q:How to receive a quotation?

A:Please send us inquiry via Alibaba or send to our email directly and offer your company information to us.

After receiving your inquiry, we will reply within 24 hours to fulfill your requirements.



Q:How to choose a suitable type/ model of machine?

A:The detail catalog can show common specification of machine,

If you want to customized the products, you can show us your detailed requirements and discuss with sale representative.



Q:Do you accept customized order?

A:Yes, machine specifications can be customized.



Q:Which kind of materials can be processed on this machine?

A:Different machines can use different materials. If you want to know more information, please contact with sale representative.



Q:Do you have overseas service?

A:No ,but we normally help our customer to solve the problem through phone ,e-mail ,Skype and internet video. We have one year guarantee ,within one year, if the component of the machine broken, we offer the component freely, but the delivery fee should be paid by client.
